AV-200

Whip Antenna RA Miller Part #: AV-200

$139.00

The AV-200 ELT antenna is intended for use with an ELT (Emergency Locator Transmitter) for General Aviation. It is a passive two frequency wire whip, designed for low-speed aircraft (up to 250 knots).

AV-300

ELT Antenna RA Miller Part #: AV-300

$229.00

This antenna is intended for use with an ELT (Emergency Locator Transmitter) for general aviation. It is a passive three frequency fiberglass rod whip antenna, designed for low speed aircraft (up to 350 knots).

AV-520

VOR/LOC/GS Antenna RA Miller Part #: AV-520

$349.00

The AV-520 is a “V” style VOR/LOC/GS antenna utilizing detachable painted stainless steel elements and internal balun transformer. The antenna is rated at speeds up to 350 mph and altitudes up to 50,000 feet. It is a direct replacement for the CI 159C.

AV-10

VHF Comm Rod Antenna RA Miller Part #: AV10

$209.00

This antenna is a direct replacement for the CI 121. The AV-10 is designed for high-performance aircraft applications. It exhibits excellent electrical characteristics and incorporates an efficient aerodynamic 4-bolt mounting base. The antenna essentially matches the styling of the communication antennas currently used on most singles and light twins.

AV-17

VHF Comm Bent Whip Antenna RA Miller Part #: AV17

$239.00

This antenna is a direct replacement for the CI 122. The AV-17 is designed specifically for mounting to the underside of an aircraft, providing an excellent radiation pattern for air-to-ground communications. It has a 4-bolt mounting base and is low in profile. The antenna is designed to operate at speeds up to 350 mph and altitudes up to 50,000 ft.

AV-22

Transponder Antenna RA Miller Part #: AV22

$99.00

This antenna is a direct replacement for the CI 101. The AV-22 is a transponder antenna which utilizes a "BNC" connector that allows for a smaller mounting hole. The antenna is designed to operate at speeds up to 350 mph and altitudes up to 50,000 ft. It has a drag force of 0.41 lb @ 250 mph.

AV-74

DME/Transponder Blade Antenna RA Miller Part #: AV74

$148.00

This antenna is a direct replacement for the CI 105. The AV-74 is a broadband blade type antenna for transponder or DME application. The antenna housing is constructed of an acrylonitrile-styrene-acrylic (ASA) shell. The white color allows maximum performance without losses due to color pigments or unseen dirt.

AV-569

Boat Type Marker Beacon RA Miller Part #: AV569

$205.00

The AV-569 is a Boat Type Marker Beacon antenna designed for very low drag. It is constructed of an acrylonitrile-styrene-acrylic (ASA) shell with the internal parts encapsulated in rigid urethane foam for mechanical and electrical stability. The white color allows maximum performance without losses due to color pigments or unseen dirt.

AV-570

Diplexer, VOR/LOC/GS Receive Only RA Miller Part #: AV-570

$159.00

This product is a direct replacement for the CI 507. The AV-570 diplexer splits the signal from a VOR-Type NAV antenna to feed a NAV/LOC and a GS receiver. The diplexer construction is similar to the AV-547 splitter and operates at altitudes up to 50,000 ft.

AV-571

TRIPLEXER 1VOR ANT to 2NAV/1GS RA Miller Part #: AV571

$199.00

The AV-571 diplexer/splitter splits the signal from a VOR-type antenna to feed two NAV and one Glide Slope receivers. The diplexer/splitter’s construction is similar to the AV-547 splitter and operates at altitudes up to 50,000 ft. This product is a direct replacement for the CI 505.

AV-532

VOR/LOC/GS Receive-only Antenna RA Miller Part #: AV532

$269.00

The AV-532 is a VOR/LOC/GS receive only antenna which consists of taper ground high-strength 17-7PH stainless steel elements to reliably withstand vibration and wind loads. The insulators are weather-sealed compression-molded bakelite with the mounting holes provided. The antenna is designed to operate at speeds up to 350 mph and altitudes up to 50,000 ft.

AV-801

GPS/WAAS Antenna RA Miller Part #: AV801

$349.00

The AV-801 WAAS GPS antenna is designed specifically to meet FAA TSO-C190 specifications. Qualification testing includes meeting the requirements of RTCA DO-301 and DO-160G. The AV-801 fit and function matches the ARINC 743A standard found on many general aviation aircraft up to and including business jets.
