The AV-300 ELT antenna is intended for use with a 406 MHz ELT (Emergency Locator Transmitter) for General Aviation. It is a passive three frequency fiberglass rod whip antenna, designed for low speed aircraft (up to 350 knots). It has met DO-160G, Section 8, Category U requirements for robust vibration and is qualified for installation on helicopters with unknown rotor frequencies.
- Application: Airborne ELT
- Frequency: 121.5, 243 & 406 MHz
- VSWR: 2.0:1 Max at 121.5 MHz; 2.0:1 Max at 243 MHz; 1.5:1 Max at 406 MHz
- Polarization: Vertical
- Impedance: 50 OHMS
- Pattern: Omnidirectional
- Weight: 9 oz.
- Height: 14"
- Connector Type: BNC (female)
- RF Power Capability: 10 Watts CW
