Includes about 600 feet of Tefzel wiring, connectors, gold plated terminal pins, 5-conductor trim wire, backshell for connectors, shielded data wire, diodes, rubber boot, and assorted insulated crimp terminals. Wiring harness has power connector terminals crimped on wires.
| QTY | GAUGE | LENGTH | COLOR | TERMINAL |
| 1 | 20 | 50ft | WHITE | NONE, MISCELLANEOUS SWITCHES |
| 1 | 22 | 80ft | WHITE | NONE, MISCELLANEOUS SWITCHES |
| 1 | 14 | 10ft | BLACK | NONE, MISCELLANEOUS GROUNDS |
| 1 | 18 | 20ft | BLACK | NONE, MISCELLANEOUS GROUNDS |
| 1 | 20 | 40ft | BLACK | NONE, MISCELLANEOUS GROUNDS |
| 3 | 14 | 20ft | WHITE | FEMALE, POWER CONNECTORS |
| 8 | 18 | 10ft | WHITE | FEMALE, POWER CONNECTORS |
| 2 | 18 | 15ft | WHITE | FEMALE, POWER CONNECTORS |
| 10 | 20 | 5ft | WHITE | FEMALE, POWER CONNECTORS |
| 2 | 20 | 20ft | WHITE | FEMALE, POWER CONNECTORS |
| 5 | 18 | 5ft | BLACK | FEMALE, GROUND WIRES FOR VP-X |
| 1 | 24/3CS | 20ft | WHITE | NONE, DATA AND FLAP POSITION CABLE |
| 2 | 20 | 5ft | WHITE | MALE, TEST LEADS |
| 1 | 25/5CS | 35ft | WHITE | NONE, PITCH AND ROLL TRIM CABLE |
