The CI 105-16 is a broadband and rugged antenna designed for DME or transponder use. The antenna assembly is encased in a glass reinforced polyester molded shell and has an extended two stud mounting configuration. Tested to the tougher DO-160D environmental requirements, it offers the best in ruggedness and performance.
This antenna was designed specifically to replace the Honeywell Bendix-King KA60. It includes a BNC connector, covers 960 - 1220 MHz frequencies and is rated to 400 Knots TAS at 25,000 ft.
- Encased in a glass reinforced polyester molded shell
- Extended two stud mounting configuration
- Includes a BNC connector
- Weight: 0.2 lb
- Height: 3.23 in
- Finish: polyurethane enamel
- Connector: BNC (female)
- Frequency: 960 MHz to 1220 MHz
- VSWR: 1.5:1 @ 960-1220 MHz, maximum; 1.3:1 @ 1025-1150 MHz, maximum
- Polarization: Vertical
- Radiation pattern: equivalent to a 1/4 wave stub
- Impedance: 50Ω
- Resistance DC: open circuit
- Power RF: 2.5 KW Peak
- Temperature: -55°C to 85°C
- Altitude: 70,000 ft
- Airspeed: 400 Knots TAS at 25,000 ft
