When panel space is at a premium, the compact SL30 nav/comm transceiver and SL 40 comm fit a lot of capability in a surprisingly small package.
Save Space, Reduce Workload
SL30 packs a 760-channel VHF comm transceiver and 200-channel VOR/LOC/GS nav receiver with DME display into one small space. Besides traditional nav/comm features, SL30 also incorporates workload-reducing functions such as automatic decoding of the Morse code station identifier for VOR/LOC/ILS, most-used frequency storage in unit memory, built-in course deviation indicator and more.
Get Two for the Price of One
SL30 is the only panel-mount nav/comm with a standby frequency monitoring feature providing the capability of two nav/comms in one. With the primary VOR/LOC frequency providing guidance to your HIS or CDI, the standby frequency can be tuned to a second VOR to display the current radial on which your aircraft is flying. This allows you to cross check position fixes with just one receiver.
SL30: Think slim.
- 200-channel Nav with solid-state DSP technology
- VOR/Localizer and Glideslope receivers
- Built-in VOR/Localizer converter
- VOR receiver displays to/from and radial
- Digitally decoded OBS setting
- Sunlight-readable full-alphanumeric display
- User-selectable back course approach mode that provides "chase the needle" operation
- Automatic display of station ID by decoding Morse code
- Interfaces to most CDI (w/resolver), HSI, and autopilot systems
- Accepts 10 to 40 Vdc input
- 760 communications channels
- Frequency range 118 to 136.975 MHz
- Active and standby flip/flop frequencies
- Volume control
- Tunes to National Weather Service Broadcasts
- Transmit status indicator
- Automatic display intensity control
- 2X8 frequency memory and recall
- Stores/Recalls 8 user defined frequencies
- Stores/Recalls previous 8 frequencies used
- Frequency monitor function (listens to standby while monitoring active)
- Dedicated emergency channel selector
- Squelch test function
- Stuck Mic time-out
- 12-watt audio amplifier
- Includes two-place VOX intercom.
- Dimensions: 1.3"H x 6.25" W x 10.5" D
- Weight: 3.3 lbs.
- Depth: 11.452 inches (29.09cm) behind panel, including mounting frame and connectors.
- Certified TSO: C34e, C36e, C40c
- JTSO
- SL30 nav/comm, unit only
*Note that the installation kit is not included.
