Easy Installation

Installation is as simple as replacing your nav light.

No airframe modifications or additional antennas are required, skyBeacon uses the existing mounting location and wiring.

All-in-one ADS-B solution includes:

  • UAT ADS-B Out
  • Integrated WAAS GPS
  • Works with any Mode C transponder wirelessly
  • Supports Anonymous Mode
  • Integrated LED Navigation light

Goof-Proof Configuration

Don’t know your ICAO or lateral GPS offset? No problem.

The skyBeacon mobile application will automatically configure the ICAO address, emitter type, aircraft length, width and GPS offsets by accessing the aircraft registration information stored online.

Ready for 2020

Everything you need for 2020 and beyond

  • Broadcasts on the UAT/978MHz frequency for operation up to FL180 within the U.S
  • WAAS GPS
  • Supports Anonymous Mode
  • Coming early 2018 for Certified Aircraft

  • Input Voltage: 11-31V DC
  • Operating Power: 3 watts
  • Size: 124x116x48mm
  • Weight: 90 grams
  • SDA/SIL: 2/3
  • Operating Temp: -45°C to 80°C
  • 978MHz UAT Transmitter Power Classification: DO-282B Medium Power
  • WAAS GPS: Tracking -166dBm, Reacquisition -160dBm, Cold Start: -148dBm
  • LED Color: Aviation Red
  • LED Intensity: 40 candelas
  • Wi-Fi Configuration: 802.11b/g/n
  • App Compatibility: iOS, Android
  • Power Transcoder: Decodes Mode A, C and S via DC input
