Garmin Announces Certification of GFC 600H

Garmin is pleased to announce it has received FAA STC for the GFC 600H helicopter flight control system (HFCS) in the Airbus Helicopters AS350 B2/B3 models. The attitude-based (AHRS-derived) flight control system boasts a number of helicopter-tailored safety features, including attitude hold (ATT), Garmin Helicopter Electronic Stability and Protection (H-ESP), dedicated return-to-level (LVL) mode, hover assist, as well as overspeed and low speed protection. The GFC 600H requires either the G500H or G500H TXi flight display and offers integration with compatible instruments and navigation sources.

With its advanced AHRS technology and redundant, cross-checking sensors, the GFC 600H was designed for smooth handling and continuously provides inputs to help stabilize the helicopter while hand-flying. The stability provided by the GFC 600H system offers significant workload reduction and greatly benefits helicopter operators by maintaining a commanded attitude. Designed with the pilot in mind, its cyclic-mounted trim controls allow for seamless interactions without taking a hand off the helicopter flight controls during basic operations, including system initialization of ATT mode, adjustments of the pitch and roll trim, and much more. While flying with ATT, pilots can easily “fly through” the flight control inputs for smooth maneuvers beyond the preset trim condition.

Hover assist mode is capable of automatically detecting a hover condition and provides flight control inputs to help maintain position over the ground. With yaw axis control, the GFC 600H will also hold heading while in a hover. In addition to hover assist mode, groundspeed hold (which requires a GTN or GTN Xi navigator) is also available and allows the pilot to input a forward or sideways command, which can be particularly useful during taxi and take-off.

Garmin H-ESP helps the pilot remain within a safe flight envelope when hand-flying the helicopter. H-ESP works in all modes – even when the system is not engaged – and can be manually disabled should the pilot choose to do so. The GFC 600H also features a dedicated level mode that can be engaged by the pilot to return to straight-and-level flight, helping to avoid a potential loss-of-control scenario. For example, in the event the pilot inadvertently enters the clouds, Garmin H-ESP can engage to assist in maintaining the helicopter in a safe flight attitude.

For enroute and approach navigation, the system uses guidance from a compatible Garmin navigator, such as the GTN Xi series, to automatically fly approaches and search and rescue patterns (when enabled). Additional vertical and lateral modes include altitude hold, altitude select, vertical speed, indicated airspeed and heading select.

The GFC 600H features a standard mark-width mode controller with push-button controls and a night vision goggle (NVG) compatible display. Its robust architecture allows the 3-axis configuration to provide the features and handling characteristics needed for a helicopter. Integrated “smart” servos provide pitch and roll inputs as commanded by the system, and the third servo and collective sensor provide yaw axis control capability and smooth flight control adjustments when the pilot moves the collective. Digitally controlled, high-torque servos allow for faster, crisper, more powerful response, which enables the GFC 600H to perform with smooth efficiency and advanced capability.

With its extensive features and advanced technology, the GFC 600H offers unprecedented value at a competitive price in a flight control system for helicopters and is expected to begin shipping in late February. The GFC 600H is supported by Garmin’s award-winning aviation product support team, which provides 24/7 worldwide technical and warranty support.
