For use with Garmin G3X systems.
Contents of 15 Pin Connector Kit (011-03002-01) contains mounting hardware:
- Backshell w/Hdw, Jackscrew, 15/26 pin (p/n 011-01855-01, qty: 1)
- AN3-7A, Bolt (p/n 211-00090-05, qty: 4)
- AN960, Cad Plate, #10 Washer (p/n 212-00035-10, qty: 4)
- Washer, Int Star, MS35334, #10 (p/n 212-00081-03, qty: 4)
- D-Sub, Crimp Socket Connector, 15 CKT (p/n 330-00625-15, qty: 1)
- Contact Socket, Mil Crimp, Size 20, 20-24 AWG (p/n 336-00022-02, qty: 15)
Contents of 9 Pin Connector Kit (p/n 011-03002-00)
- Backshell w/Hdw, Jackscrew, 9/15 pin (p/n 011-01855-00, qty: 1)
- CAN Termination Kit (p/n 011-02887-00, qty: 1)
- D-Sub, Crimp Socket Connector, 09 CKT (p/n 330-00625-09, qty: 1)
- Contact Socket, Mil Crimp, Size 20, 20-24 AWG (p/n 336-00022-02, qty: 9)
