MFD Versatility With Full PFD Backup

Clean up your panel and remove vacuum system and backups with optional external battery

The Evolution™ 2000 MAX combines the powerful, award-winning Pro MAX Primary Flight Display (PFD) and the MFD1000 MAX Multi-function Display (MFD) to provide a system with MFD versatility and twice the safety and redundancy.

The Pro MAX PFD and MFD1000 MAX provide the safety and confidence of PFD redundancy. If your PFD fails, simply press the REV button on the 1000 MFD and it becomes the PFD – converting into an identical backup right in your primary instrument scan. This PFD backup means less stress and potential confusion in a pressure situation. No other GA glass cockpit system gives you this level of redundancy and confidence at any price.

Aspen makes the total glass cockpit experience both easy-to-use and affordable with patented retrofit technology and superior compatibility for substantially lower installation costs and total cost of ownership.

Evolution 2000 MAX – exceptional versatility, unmatched redundancy.

  • Reduces cockpit clutter
  • Evolution 2000 system with optional external backup battery allows removal of your backups along with vacuum system
  • Vibrant aviation glass with the latest generation of processors
  • Simple and affordable MAX upgrade path for legacy Aspen displays

Evolution 2000 MAX Features:

  • Advanced EFIS six-pack replacement
  • Pro MAX PFD/MFD redundancy backs up all critical sensors and systems
  • Twice the display area for enhanced situational awareness
  • Built-in backup battery and emergency GPS
  • New, vibrant colors with the latest aviation glass
  • Higher reliability and faster refresh rates with the latest generation processors
  • Brilliant, direct sunlight-readable, 6-inch 760x400 TFT active matrix LCD display capable of displaying over 30 million colors (140 pixels/inch)
  • Photo-quality moving maps and crisp, clear text
  • Terrain, traffic, maps and weather
  • ADS-B In weather and traffic (with compatible ADS-B transceiver, receiver or transponder)
  • Audio panel interface
  • Fully expandable and software upgradable – when new technology becomes available no need for unit replacement
  • Optional Evolution Synthetic Vision and Angle of Attack
  • Works with your existing avionics with broadest autopilot/flight director integration
  • Lightest weight with easy system installation
  • Award-winning customer service
  • No-nonsense warranty

Pro MAX PFD Features:

  • GPS-aided AHRS in the event of pitot static failure
  • Font and window enlargement capable
  • Airspeed and altitude tapes
  • Altitude alerter (and separate approach minimums alerting)
  • Full electronic HSI with dual bearing pointers
  • Base map with flight plan legs and waypoints, nearby navaids, curved flight paths (with compatible GPS navigators)
  • Built-in GPS steering (with compatible GPS navigators)
  • Display of real-time winds aloft, OAT, TAS, and ground speed (with compatible GPS navigators)
  • Integral Air Data Computer and Attitude Heading Reference System (AHRS)

MFD1000 MAX Features:

  • Duplicate sensor set providing PFD redundancy on MFD if PFD fails
  • Allows removal of redundant mechanical backup instruments (Optional battery backup required)
  • Secondary HSI
  • Chart and countdown timers
  • Height above ground level (AGL) on navigation and terrain maps
  • METAR flags on navigation map
  • High resolution moving maps with hazard display overlays
  • ADS-B traffic and weather (with compatible ADS-B transceiver, receiver or transponder)
  • Customizable screen layouts
  • Font enlargement
  • Charts and geo-referenced airport diagrams

General Specifications (per EFD):

  • Overall Dimensions: 3.50"W x 7.00"H x 4.15"D
  • Weight: 2.9 lbs. with mounting bracket
  • Display Type: 6.0" Diagonal TFT Active Matrix LCD
  • Display Resolution: 400x760
  • Display Backlight: High Intensity White LED
  • Display Colors: 30 Millon Colors(140 pixel/inch)

Operational Specifications:

  • Operating Temp: -20°C to +55°C
  • Storage Temp: -55°C to +85°C
  • Max Operating Altitude (unpress.): 35,000 ft.
  • Cooling: Integral Fan
  • Max Humidity: 95% at 50°C
  • Input Voltage: +8 to +32 Volts DC
  • Max Current: 2.4 Amps @ 28 Vdc / 4.8 Amps @ 14 Vdc

I/O Specifications:

  • ARINC 429 Inputs: 5 Low Speed
  • ARINC 429 Outputs: 1 Low Speed
  • RS-232 Inputs: 5
  • RS-232 Outputs: 3
  • Pitot / Static: Quick Connect

Certification Specifications:

  • Software: RTCA DO-178B Level C
  • Environmental: RTCA DO-160E

  • EFD1000 Pro MAX PFD
  • EFD1000 MAX MFD - Internal Battery, Americas

Optional:

  • EFD1000 MAX MFD with External Battery
