Evolution 1500 MAX - Making Glass Cockpit Systems Flexible and Affordable.

The Evolution™ 1500 MAX display system delivers powerful, full-featured glass panel performance at the lowest price on the market.

Versatile and exceptionally easy-to-use, the combination of our Pro MAX Primary Flight Display (PFD) and MFD500 MAX Multi-function Display (MFD) gives you the advanced capabilities to make flights safer and more enjoyable.

Aspen makes the total glass cockpit experience both easy-to-use and affordable with patented retrofit technology and superior compatibility for substantially lower installation costs and total costof ownership.

Evolution 1500 MAX – most flexible, most compatible, lowest cost.

  • Advanced EFIS six-pack replacement
  • Twice the display area for enhanced situational awareness
  • Built-in backup battery and emergency GPS
  • New, vibrant colors with the latest aviation glass
  • Higher reliability and faster refresh rates with the latest generation processors
  • Brilliant, direct sunlight-readable, 6-inch 760x400 TFT active matrix LCD display capable of displaying over 30 million colors (140 pixels/inch)
  • Photo-quality moving maps and crisp, clear text
  • Terrain, traffic, maps and weather
  • ADS-B In weather and traffic (with compatible ADS-B transceiver, receiver or transponder)
  • Audio panel interface
  • Fully expandable and software upgradable – when new technology becomes available no need for unit replacement
  • Optional Evolution Synthetic Vision and Angle of Attack
  • Works with your existing avionics with broadest autopilot/flight director integration
  • Lightest weight with easy system installation
  • Award-winning customer service
  • No-nonsense warranty

General Specifications (per EFD):

  • Overall Dimensions: 3.50"W x 7.00"H x 4.15"D
  • Weight: 2.9 lbs. with mounting bracket
  • Display Type: 6.0" Diagonal TFT Active Matrix LCD
  • Display Resolution: 400x760
  • Display Backlight: High Intensity White LED
  • Display Colors: 30 Millon Colors(140 pixel/inch)

Operational Specifications:

  • Operating Temp: -20°C to +55°C
  • Storage Temp: -55°C to +85°C
  • Max Operating Altitude (unpress.): 35,000 ft.
  • Cooling: Integral Fan
  • Max Humidity: 95% at 50°C
  • Input Voltage: +8 to +32 Volts DC
  • Max Current: 2.4 Amps @ 28 Vdc / 4.8 Amps @ 14 Vdc

I/O Specifications:

  • ARINC 429 Inputs: 5 Low Speed
  • ARINC 429 Outputs: 1 Low Speed
  • RS-232 Inputs: 5
  • RS-232 Outputs: 3
  • Pitot / Static: Quick Connect

Certification Specifications:

  • Software: RTCA DO-178B Level C
  • Environmental: RTCA DO-160E

  • EFD1000 Pro MAX PFD with Synthetic Vision
  • EFD500 MAX MFD - Internal Battery, Americas
