EGT/CHT, Shock cooling, LOP/ROP, Volts, Hi/Lo Alarms, Google Map, USB

Displays EGT’s, CHT’s, TIT and/or Oil Temp (digital and bar graph display). Other temperatures & functions will be displayed digitally only. Engine analysis performed automatically with Pilot Programmable Over-Temp Limits, a Differential Limit and a Shock-Cooling Limit. Range for Bars and Scan Rate are also Pilot Programmable. Proprietary Peak Detect for ROP and LOP eliminates false peak readings. Indicates as each Cylinder reaches Peak EGT. Displays Temperature Below Peak EGT for accurate Leaning. Fuel/Air Mixture Profiling. Normalized Mode with Long Term Memory for Easy Problem Detection and Trend Analysis. Charting and download software included free.

Available Options: Fuel Flow, RPM, MAP, EGT, CHT, TIT (two), Oil Temp, Oil Pressure, OAT, Volts, CARB Temp, CDT, IAT, %HP, EGT SPAN, GPH, USD, REM, REQ, MPG, USB Data

With the EDM 730, it is now possible to have substantially more diagnostic information available to you in a timely and usable manner.

  • Improved engine efficiency
  • Reduced maintenance costs
  • Greater fuel economy
  • Reduced operating costs
  • Smoother engine operation
  • Proper engine temperatures
  • Longer spark plug life
  • Reduced engine vibration

  • Fits a standard 3.1" hole
  • Housing off center
  • Rotates 90 degrees 4 times
  • Fits the standard JPI harness
  • EDM-700/800 upgradable
  • LeanFind (tm) Performs ROP and LOP, automatically finds the first and last cylinder to peak
  • Shock cooling checked on all cylinders with an alarm on the cylinder with the highest cooling rate
  • Voltage, for alternator failure, monitored for over and under voltage with alarms
  • Pilot Programmable Hi & Lo alarm limits. ALL programming from front panel
  • All EDM’s TSO’d for quality
  • 3 year warranty (Electronics)
  • 1 year warranty (Probes)
  • Quick response probes, fastest accurate readings, harness and hardware
  • Data Memory, reading once every 2 to 255 seconds. To be down loaded to USB stick
  • EZPlot-1 program for downloading data and plotting data
  • USB down load port built in with memory stick
  • Full color TFT screen

  • Dimensions: 3.25" x 4.25" footprint with a 3-1/8" mount, 2" deep
  • Weight: 13 oz.
  • 3 oz. for each probe

  • EGT probes
  • CHT probes
  • Volts
  • Shock cooling
  • Span (highest to lowest EGT)
  • LOP/ROP JPI Exclusive Leaning Mode
  • Power connector
  • EGT/CHT Harness
  • EZTrends
  • Data recording-100 hrs. Download USB
  • 1 GB memory stick
  • Selectable Positions for Linear gauges
