- Provides reliable power for cabin and exit lighting in the event of main electrical failure
- 56 watt-hour capacity
- 132 minutes @ 1.0A (56Wh capacity) run time
- Utilizes Nickel Metal Hydride (NiMH) battery technology
- 20 – 30 VDC input voltage
- 24.6 VDC nominal, 3 amps maximum output power
- Can be fully recharged or maintain existing full charge via the aircraft’s primary power bus
- Direct replacement for Radiant 640-13595-00/7450LS-00 power supplies
- 2-year maintenance schedule
- 6–8 years battery life expectancy
- Designed and built in Wichita, Kansas USA
- Two-year limited warranty
- FAA TSO Certified
- Capacity: 56 watt-hour
- Input Voltage: 20 – 30 VDC
- Output Power: 24.6 VDC nominal, 3 amps maximum
- Technology: Nickel Metal Hydride (NiMH)
- Weight: 2.9 lbs
- Dimensions: 9.1”L x 4.3”W x 2.4”H (231.14mm x 109.22mm x 60.96mm)
- Direct Replacement: Radiant 640-13595-00/7450LS-00
- Battery Life Expectancy: 6 – 8 years
- Protection: Short circuit, over temperature, under-voltage, over-voltage, and EMI filtering
- Mating Connector: D38999/26WC35SN
- Case: Anodized aluminum
- Certification: FAA TSO-C173a certified, RTCA DO-293A qualified, RTCA DO-160G qualified
