PLEASE NOTE: The main image displays the round unit p/n M655-2. The second image is of the rectangular unit p/n M655-1. If you require the 655-1, please specify during checkout.
Davtron’s Model 655 is a computer-based product that computes density altitude automatically. No longer does the pilot need to retrieve outside air temperature and pressure altitude, then enter this into a flight computer. The Model 655 measures outside air temperature, and accepts pressure altitude information from the blind encoder or encoding altimeter, then converts this information to a direct read-out of density altitude. The density altitude is computed using U.S. standard atmosphere tabulation. Take-off roll, maximum rate of climb, and fuel consumption are all determined easily from density altitude and the aircraft’s flight manual.
- OUTSIDE AIR TEMPERATURE (°F)
- OUTSIDE AIR TEMPERATURE (°C)
- PRESSURE ALTITUDE
- DENSITY ALTITUDE
- AIRCRAFT VOLTAGE With ALARM
- ALTITUDE ALARM
- Weight: 5 oz.
- Warranty: 1 year
- Density altitude: – 10,000 to 30,000 ft.
- Pressure altitude: – 1,000 to 62,700 ft.
- (Depends on encoder range.)
- Flashing annunciator character on incorrect encoder inputs.
- Voltage range 10V to 32V ± .2 volts Typ.
- LED with automatic dimming.
- Input voltage: 14 or 28 volts.
- Input current: .35 amps max.
